PTM600S-AQI Portable Air Quality Monitor
PTM600S-AQI portable intelligent air quality monitor is used to accurately detect and analyze various gas concentrations and temperature and humidity, particulate matter, air pressure, wind speed, wind direction, radiation, etc.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Introduction
PTM600S-AQI portable intelligent air quality monitor is used to accurately detect and analyze various gas concentrations and temperature and humidity, particulate matter, air pressure, wind speed, wind direction, radiation, etc. The monitor with 5-inch color screen for real-time display which is touchable. PTM600S-AQI is widely used in firefighting, emergency rescue, confined space, petroleum, chemical industry, metallurgy, refining, gas, warehousing, medicine, environmental protection, flue gas analysis, air treatment and other occasions. The instrument is powerful and supports various additional function customization. It can be regionally networked, interconnected, remote wireless transmission, MESH transmission (remote transmission of confined space data and video), data upload to the cloud platform, with phone APP for remote alarm reminding.
FEATURES
- ISO,CE,FCC, ROHS, ATEX,CNEX,SIL3 Approved
- Up to 30 gas pollutants with ppb accurancy
- Simultaneously measures metrological parameters such as temperature and humidity, particulate matter (PM0.1, PM2.5, PM10 and TSP), air pressure, wind speed, wind direction, noise, rain, radiation, etc.
- With smart separate module plugin design, support any gas changing and replace.
- Unit switching, optional units: umol/mol, ppm, mg/m3, ppb, ug/m3, %Vol, %LEL.
- Built-in pump, support 10 levels of flow adjustable.
- 5-inch touchable color screen
- Android operating system, support remote maintenance and OTA remote wireless upgrade.
- 16G storage capacity, larger capacity optional, support multiple storage methods.
- Multi type communication interface: TYPE-C, WIFI, Bluetooth
- Optional wireless transmission options: LORA, MESH, 4G, NB-IOT, etc.
- Standard functions: GPS/Beidou precise positioning, LED lighting, SOS one-key call function, human fall-down alarm, one-key positioning upload, display user information, real-time location, concentration information, longitude and latitude and custom address information, trajectory query, etc. on the map.
- Optional functions: one-key photo taking (greater than 800W pixels), video recording, local video viewing, etc.;
- Data statistical analysis function;
- Factory parameters and stored data recovery function
- Sound, light and vibration alarms (95 dB at 30 cm)
- Alarm types: LOW, HIGH, TWA ,STEL
- Auto misoperation identification function
- Automatic zero point tracking
- Multi-level calibration
- IP68 Protection level
SPECIFICATIONS
Detection parameters:
CO, SO2, NO2,O3,PM2.5 &PM10, T&H, WS &WD
- CO: Electrochemical sensor, 0-25ppm, 0.01ppm resolution
- SO2: Electrochemical sensor, 0-10ppm, 0.01ppm resolution
- NO2:Electrochemical sensor, 0-1ppm, 0.001ppm resolution
- O3: Electrochemical sensor, 0-1ppm, 0.001ppm resolution
- PM2.5: laser sensor,0-1000ug/m3, 1ug/m3 resolution
- PM10: laser sensor, 0-1000ug/m3, 1ug/m3 resolution
- Humidity: 0-100%
- Temperature: -40 ~120°C
- Wind speed: 0-40m/s
- Wind direction: 0-360°
- Accuracy:≤±2% (F.S)
- Respond time: T90≤20S
- Detection method: Pumped, flow rate could be adjusted, with pump-block reminder
- Working power consumption: DC 3-5V
- Battery: 25000mAh rechargeable Li-battery
- Protection level: IP66
- Product Size: 340x330x150mm(L×W×H)
- Weight: 4.5Kg (will be different according to the different parameters)
- Protection grade: Exia II CT4 Ga /Ex ib I Mb
- Working environment: -40°C~+70°C, ≤95%RH (non-condensing occasions)
- Warranty time: 1 year
