Internal Audible Alarm USB Airborne Particle Counter Portable

  • Internal Audible Alarm USB Airborne Particle Counter Portable
  • Internal Audible Alarm USB Airborne Particle Counter Portable
  • Internal Audible Alarm USB Airborne Particle Counter Portable
Place of Origin China
Brand Name Zetron
Certification CE
Model Number B330
Minimum Order Quantity 1 set
Price USD 145/set- 879/set
Packaging Details 130*68*34mm
Delivery Time 1-10 work days
Payment Terms T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability 1000 SET / week
Product Details
Type Airborne Particle Counter Alarm Mode Internal Audible Alarm
Flow Rate 100 L/min Power 220V±10%,50Hz±2Hz
Size 220*280*260 Mm Weight 8.5 Kg
Highlight

internal audible alarm airborne particle counter

,

usb airborne particle counter

,

usb portable airborne particle counter
Leave a Message
Product Description

ZLJ-B330 Portable Airborne Particle Counter



OVERVIEW



With fast, reliable sampling of one cubic meter of air in only ten minutes, the ZLJ-B Series Portable Airborne Particle Counters offer fast cleanroom qualification and at sensitivities of 0.3 microns. ZLJ-B Series incorporate our Extreme Life Laser Diode Technology sensor to produce the industry’s long life-time laser diode. The ZLJ-B330 is the industry’s 28.3 LPM 0.3 micron portable designed for continuous use. ZLJ-B Series are adopted the industry’s UI (User Interface) to configure andoperate the instrument. The intuitive ICON-driven screens and menus are easy to learn and use, and support multiple languages.
They can store up to 5,000 records of particle count data from up to 8 particle channels and the configurable recipe database can store up to 50 recipes for sampling and reports. All data can be quickly and reliably transferred to a computer.
Data transfer to a USB Flash Drive can be accomplished by using the software.
Flexible communication with these instruments is made possible by the integrated Ethernet, RS-485, USB and WIFI. ZLJ-B Series are designed, manufactured and calibrated to ISO14644 to ensure particle counting accuracy



SPECIFICATION



Model
ZLJ-B1030
ZLJ-B550
ZLJ-B330
Size Range
0.3 - 10.0 µm
Channel Sizes
8-Channel: 0.3, 0.5, 0.7, 1.0, 2.0, 3.0, 5.0, 10.0 µm
Flow Rate
100L/min
50L/min
28.3L/min
Concentration Limits
35,000 particles/L
Light Source
Laser diode (30,000 hours mean time between failure)
Dimensions(mm)
223*348*250
220*285*260
220*285*260
Weight(Kg)
7.1
9.0
8.5
Sample Period
1 Sec~5999 Sec(5L-5000L)
Calibration Count Modes
Meets ISO14644 calibration ,GMP-2010
Date Storage
2000 samples
Communication Modes
WIFI, RS-485,Ethernet, USB,Software
Environmental Sensors
(Optional)
Temperature, Relative Humidity, Air Velocity, Differential Pressure,
Battery or others
Touch Screen Display
9.1 inch (23 cm) color TFT touch screen display
Reports
Pass/fail report wizard for ISO-14644 and FS-209E report formats
Alarms
Integrated alarm buzzer. Alarms on counts, low battery (optional)
Enclosure
Stainless Steel
Power
220V±10%,50Hz±2Hz
220V±10%,50Hz±2Hz
Battery
built-in lithium battery
Optional Li-Ion, removable & rechargeable (typical recharge time 5 hours)
Languages
English/Chinese/Customize


Internal Audible Alarm USB Airborne Particle Counter Portable 0Internal Audible Alarm USB Airborne Particle Counter Portable 1Internal Audible Alarm USB Airborne Particle Counter Portable 2Internal Audible Alarm USB Airborne Particle Counter Portable 3Internal Audible Alarm USB Airborne Particle Counter Portable 4



APPLICATION



Particle Counters are feature-rich instruments that are ideal for spot-checking inside of your critical environments or Indoor Air Quality applications. With its compact size and weight along with its sleek handle, you can utilize this unit with ease.

These units provide immediate results that allow you to proactively monitor your environment.
It's widely used in Automotive Manufacturing; Coating Processes; Paint Booth; Aerospace Flight and Space; Hardware Manufacturing; Flat Panel Display Manufacturing; Medical Device Manufacturing
Electronic Industry (semiconductor factory, precision machinery production and processing, etc);Food Hygiene Industry (dairy products, plastic meat food, seasoning food, agricultural products, etc); Filter Manufacturers, inspection filter quality and efficiency, etc; and other areas of precision processing, precision testing required Clean Room (area), and other testing needs.

Internal Audible Alarm USB Airborne Particle Counter Portable 5
