Th100-1 One Channel Gas Controller Alarm With 4 Relays Output

Place of Origin China
Brand Name Zetron
Certification CE
Model Number TH100-1
Minimum Order Quantity 1 piece
Packaging Details paper carton
Delivery Time 3-7 days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 10000 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Gas Alarm Controller Display High Light LED Display
Working Voltage 220V AC, 50HZ Working Environment Temperature 20℃~50℃, Humidity <95%
Input Signal 4-20mA Dimension 400mm*280mm*80mm
Weight 3.6kg
High Light

4 relays output gas detection controller

,

one channel gas detection controller

,

one channel gas alarm controller

You can tick the products you need and communicate with us in the message board.
Product name
Leave a Message
Product Description

TH100-1 Gas Alarm Controller

OVERVIEW



With the new design of the Touch screen, simple operation. It could connect the TH100 fixed gas detector to make up the industrial gas detection system. It will display the all gas concentration for each gas detector, when the gas concentration level is up to the preset data, the controller will alarm with acoustic and light signals. Synchronously, the actuator will begin to drive the exhaust or the cut-off valve and other equipment, in order to prevent the poisoning accident, explosion, or fire. The TH100 Combustible Gas detector controller and TH100 is Alarm control main engine wireless it could guarantee the security of the industrial working place.

Th100-1 One Channel Gas Controller Alarm With 4 Relays Output 0



SPECIFICATION



Item Description
Product name Gas detection controller
Display 8 inch TFT LCD touch screen
Power supply AC220V±15%, 50Hz±1%
Consumption ≤10W(according to different channels)
Output voltage DC24V±15%
Input signal RS-485/ 4-20mA
Relay output 4 relay output with optional NO or NC / customized
Relay contact capacity 5A, 30VDC or 5A, 220VAC
Alarm mode Audible, visual
Installation mode Wall-mounted
Suitable gas detector MIC100 Fixed gas detector with RS485 signal output
Gas detector quantity ≤64pc
Communication distance ≤2000m
Working temperature -10℃~+50℃
Working humidity 10~95%RH(Non-condensation)
Size 400mm*280mm*80mm
Weight About 3.6kg
Protection grade IP54
Quality standard GB 16808-2008 GB 15326-1994
Certificate CE, RoHS



FEATURES & BENEFITS



· Advance micro-processing technology

· With lock and voice elimination function

· Good stability, high precision

· High light LED nixie tube display the concentration, with two levels of alarm setting

· Relay output

· Install method: wall mounted



APPLICATION



The TH100 Gas detection controller used to connect with the fixed gas detector and the related equipment in industrial scene, such as petroleum refinery, chemical plants, LPG stations, boiler rooms, gas stations, paint spray booths, metallurgy, mining, fire, environmental protection, etc.

Th100-1 One Channel Gas Controller Alarm With 4 Relays Output 1



FAQ



Q: What are your terms of payment?
A: We accept trade assurance, western union, visa master card, and tt.
Trade assurance can protect you, when you confirm the product then the money into my account.


Q:Do you accept OEM or revised logo, color, model, size?
A: Yes, we accept OEM for the qualified buyer. We can make the products according to customer personal requirements.

Q: When do you reply to messages?
A: We will reply to your inquiry in 24 hours.

Q: What is the warranty for your product?
A: Warranty: 12 months, Lifetime maintenance

Q: When do you send the products? And how do you send it ?
A: For the small order, we will send out the goods within 5 days, If have stock, we will send it immediately.
We send them by ups, FedEx, TNT or DHL. For big order, normal is 20 days will finish.

Q: How about your after-sale service?
A: After sending, we will track the products for you, until you get the products.
When you got the goods, test them, and give me feedback.
If you have any questions about the problem, contact us, we will offer the solve way for you.
