Semiconductor Laser Hydraulic Particle Counter For Insulating Oil And Turbine Oil

Place of Origin China
Brand Name Zetron
Model Number OPC-L2
Minimum Order Quantity 1 pcs
Packaging Details Stainless steel 304 suitcase
Delivery Time 14 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 100 Piece/Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name OPC-L2 Oil Particle Counter Light Source Semiconductor Laser
Repeatability RSD<2% Sampling Accuracy Better Than ± 0.5%
Sampling Speed 5 ~80mL/min Maximum Particle Concentration 12000~40000 Particles/mL
Power Supply 110~245V AC, 50Hz, 70W Overall Dimension 340mm*410mm*650mm
Instrument Weight 25kg
High Light

semiconductor laser hydraulic particle counter

,

insulating oil hydraulic particle counter

,

turbine hydraulic oil particle counter

Leave a Message
Product Description

OPC-L2 Oil Particle Counter



OVERVIEW


OPC-L2 Portable Oil Particle Counter adopts Laser Extinction Technology, is designed to measure the particles’ size and quantity in oil liquid. It is Suitable for tests of pollution degree of solid particles in hydraulic oil, lubricating oil, fire resistant oil, insulating oil, turbine oil, organic liquid and polymer solution, etc. So our instrument can be used in aviation, spaceflight, electric power, petroleum, chemical industry, transportation, port, metallurgy, machinery, automobile manufacturing and many other fields.4.1 Power Choice: External power or Battery.


FEATURES


* Up to 64 testing channels can be set up at the same time according to customers' needs.
* Built-in data analysis system, a test can give all the standards of the test data and contamination levels
* Built-in viscosity, moisture and temperature sensor module, in the accurate testing of particle distribution at the same time to provide viscosity, moisture content saturation and ppm values and temperature reference values (optional)
* Any particle size can be set, with 9999 built-in particle sizes for easy particle size analysis.
* A variety of sampling containers such as standard sampling bottles or sampling cups can be used to meet the testing requirements of different industries
* Full-featured automatic color touch screen operation, support for Chinese and English dual interface, easy to operate
* Single-channel and multi-channel calibration can be carried out to realize the automatic calibration function.
* With RS232 interface, can be connected to a computer or laboratory platform for data processing.
* With massive data storage, printing function, can store 1000 groups of data and support U disk storage data.


APPLICATION SCENES


OPC-L2 oil particle counter can be widely used in aviation, aerospace, electric power, petroleum, chemical industry, transportation, port, metallurgy, machinery, automobile manufacturing and other fields.


PRODUCT PARAMETERS



Light source
Semiconductor laser
Particle size range
0.8μm~600μm (calibrated according to 1~100um or 4~70um(c))
Detection channels
8~64 channels optional, arbitrary setting of particle size size
Sensitivity
0.8μm (ISO4402) or 3μm(c) (GB/T18854, ISO11171)
Resolution
<10% (GB/T18854, ISO11171)
Repeatability
RSD<2%
Sample detection viscosity
≤650cSt (viscosity is too large can be combined with heating or dilution method detection)
Sampling volume
0.2~1000mL, interval 0.1mL
Sampling accuracy
better than ± 0.5%
Sampling speed
5 ~80mL/min
Pneumatic chamber
Positive and negative air pressure chamber device, to realize sample degassing and high viscosity sample detection
Maximum vacuum of air pressure chamber
-0.08Mpa
Maximum positive pressure of air pressure chamber
0.8 Mpa
Maximum particle concentration
12000~40000 particles/mL
Power supply
110~245V AC, 50Hz, 70W
Overall Dimension
340mm*410mm*650mm
Net weight
25kg
