Online Flue Gas Analyzer SO2 NO O2 Low Concentration Furnace Exhaust Emission Gas
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Measurement Component | SO2, NO, CO, CO2, O2 | Inlet Pressure | 2kPa-50kPa |
|---|---|---|---|
| Work Temperature | (0~+50)°C | Communication | RS232/RS485 |
| Resolution | 0.1ppm | Power Supply | 220V AC, 50Hz, 800W |
| Size | 485*400*132mm | Weight | 18kg |
| High Light | Online Flue Gas Analyzer,SO2 Flue Gas Analyzer,Online Flue Gas Analyser |
||
Product Description
Online Infrared Flue Gas Analyzer
OVERVIEW
Gasboard 3000UV is designed with advanced UV DOAS technology, is able to measure continuously simultaneously concentration of SO2,NO,especially for lowest range measurement. It is an ideal solution for monitoring in fields of boiler, power plant, combustion efficiency monitoring for various industrial furnaces or refuse incinerator, process and security monitoring.
FEATURES
• Adopting advanced UV DOAS technology with higher precision and longer life time.
• Monitoring the lowest range of SO2 and NO within 100mg/m³.
• No cross interference between measurement gases.
• Diagnostic function can check sensor status.
• Sampling flow rate fluctuations have no effect on the measurement results.
• Accurate measurement of low concentration gas.
• Built-in pump to achieve automatic zeroing.
• Real-time continuous monitoring.
• LCD (320*240) display.
• Digital and analog signal output.
SPECIFICATION
| General Parameter | |
| Measurement | H2S |
| Technology | UV DOAS |
| Range | low range: 0-500ppm |
| high range: 0-5000ppm | |
| (Note: measurement range can be customized.) | |
| Resolution | H2S: 1ppm |
| Precision | H2S: <2%FS |
| Repeatability | H2S: ≤1% |
| Gas flow | 0.7 to 1.2 L/min |
| Inlet pressure | 2kPa 50kPa |
| Sampling gas condition | no dust, no water vapor |
| Response time(T90) | ≤60s (UV DOAS) |
| Communication interace | RS-232 |
| Output | 4-20mA |
| Power supply | 110 v / 220 v + 44 v AC 50 hz+1hz |
| Workng Environment | |
| Work temperature | 5-35 ℃ |
| Relative humidity | ≤95%6 non condensing |
| Ambient pressure | 86-108kPa |
| Dimensions | |
| Dimension | 400*485*132mm (L"W*H) |
| Weight | 18kgs |
APPLICATION
Boiler, furnace exhaust emission gas and combustion efficiency monitoring, cement production line process and security monitoring, CEMS integration.
