0-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor

  • 0-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor
  • 0-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor
  • 0-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor
Place of Origin China
Brand Name Zetron
Certification CE
Model Number MIC500S
Minimum Order Quantity 1
Price USD 300-- 1000/set
Packaging Details paper carton
Payment Terms L/C, D/A, T/T, MoneyGram

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Fixed Gas Detector Model Number MIC500S
Display Method 1.7-inch High-definition Color Screen Protection Level IP65
Weight 1.8(kg) Size 210*170*85mm (L*H*W)
High Light

200Mg/L O3 Gas Detector

,

MIC500S O3 Gas Detector

,

200Mg/L Ozone Gas Detector
Leave a Message
Product Description

MIC500S Fixed Toxic And Harmful Gas Detector



OVERVIEW



MIC500S Series gas detector can be used in 24 hours continuous online monitoring of concentrations of multiple types of gases in the filed.The types for detection are more than 500 types.
With a 4-20 mA analogue output, can be simply integrated into a Distributed Control System (DCS) to provide warnings.
Simple to install service and calibrate, MIC500S requires no hot work permit and the PID sensor is accessible and changeable in a matter of seconds.
0-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor 00-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor 10-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor 20-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor 3


SPECIFICATION



Gases to be detected Ozone/O3 Gas Detector
Detection range

0--1000 ppm

0-- 5000 ppm

0-- 50000ppm

0-- 200mg/L

Other ranges can be customized
Resolution

0.01ppm or 0.001ppm (0 ~ 10 ppm);
0.01ppm (0 ~ 100 ppm),
0.1ppm (0 ~ 1000 ppm),
1ppm (0 ~ 10000 ppm or more),
0.01 mg/l (0 ~ 200 mg/l),
0.1% LEL,
0.01%Vol

0.001% Vol

Other ranges can be customized
Detection principle

Ultraviolet sensor

Electrochemical, infrared, thermal conductivity, PID photoionization, and so on.

Depending on the type of gas, range, field environment and user demand,

Sensor can be customized
Sensor service life

Electrochemical principle: 2 ~ 3 years;

Infrared principle: 5 ~ 10 years;

Thermal conductivity: 5 years
Allowable error ≤±3% F.S (other or higher precision levels can be customized)
Linearity ≤±2% Repeatability ≤±2% Uncertainty ≤±2%
Response time T90≤20 seconds Recovery time ≤30 seconds
Working environment Temperature: -40 ℃ ~ + 70 ℃, humidity: ≤10 ~ 95% RH (regular)
Display method 1.7-inch high-definition color screen
Working voltage

12 ~ 30VDC direct current

the standard power supply for a single equipment is 24V, DC stabilized voltage switching power supply of 1A or greater than 1A
Protection level IP65
Explosion-proof type Explosion suppression type
Explosion-proof mark ExdⅡCT6, certificate number: CNEx15.1283



FEATURES



■Integrated sound & light alarming device, split-type sound & light alarming device,
■Wireless transmission
①It is possible to transfer data wirelessly to the cell phone, remote monitoring center,
monitoring computers and other monitoring equipment, which will utilize the upper-level host to realize
the functions of data analysis, storage, printing, or the like on the computer.
■ Pretreatment system
①Room temperature and high humidity pretreatment system
②High temperature and high humidity pretreatment system
■Accessory for connection with a computer for monitoring
①Free upper-level host software, RS485 / RS232 converter
②For laptops without RS232 interface, USB / RS232 converting and connecting cable is needed,



APPLICATION

All the cases require the fixed installation, and online detection of gas concentrations such as petroleum, chemical, pharmaceutical, environmental protection, combustion gas distribution, warehousing, smoke gas analysis, air governance, and so on.

0-200Mg/L Ozone O3 Gas Detector Alarm MIC500S Outdoor / Indoor Ultraviolet Sensor 4
