Mic300 Ozone Gas Monitor Industrial Outdoor Indoor Aluminum Alloy Fixed
Product Details
| Product Type | MIC-300 | Detection Range | 0～1000, 2000, 5000, 10000ppm, 30%Vol, 100%Vol Optional |
|---|---|---|---|
| Explosive Grade | Exd II CT6/DIP A20 TA, T6 | Protection Level | IP66 |
| Material | Aluminum Alloy, Surface Anticorrosive Paint Sprayed | Warranty | 1 Year |
| Highlight | mic300 ozone gas monitor,aluminum alloy ozone gas monitor,industrial fixed ozone gas detector |
||
Product Description
MIC300 Online Toxic and Harmful Gas Detector
OVERVIEW
MIC300 Series gas detector can be used in 24 hours continuous online monitoring of concentrations of multiple types of gases in the filed.The types for detection are more than 500 types.
With a 4-20 mA analogue output, can be simply integrated into a Distributed Control System (DCS) to provide warnings and enable control of high levels in the working environment.
Simple to install service and calibrate, MIC500 requires no hot work permit and the PID sensor is accessible and changeable in a matter of seconds.
Strong, durable and explosion-proof shell and fluorocarbon surface treatment process are suitable for the use at a variety of hazardous places and corrosive environments, it is wear-resistant.
SPECIFICATION
|
Type
|
Fixed Gas Detector
|
||||
|
Detection range
|
0~ 10ppm
0~ 20ppm
0~50ppm
0~100ppm
Other ranges can be customized
|
||||
|
Resolution
|
0.01ppm or 0.001ppm (0 ~ 10 ppm);
0.01ppm (0 ~ 100 ppm), Other ranges can be customized
|
||||
|
Detection principle
|
Electrochemical, infrared, thermal conductivity, PID photoionization, and so on.
Depending on the type of gas, range, field environment and user demand,
Sensor can be customized
|
||||
|
Sensor service life
|
Electrochemical principle: 2 ~ 3 years;
Infrared principle: 5 ~ 10 years;
Thermal conductivity: 5 years
|
||||
|
Allowable error
|
≤±3% F.S (other or higher precision levels can be customized)
|
||||
|
Linearity
|
≤±2%
|
Repeatability
|
≤±2%
|
Uncertainty
|
≤±2%
|
|
Response time
|
T90≤30 seconds
|
Recovery time
|
≤30 seconds
|
||
|
Working environment
|
Temperature: -40 ℃ ~ + 70 ℃, humidity: ≤10 ~ 95% RH (regular)
|
||||
|
Working voltage
|
12 ~ 30VDC direct current
the standard power supply for a single equipment is 24V, DC stabilized voltage switching power supply of 1A or greater than 1A
|
||||
|
Power supply reference
|
24V, 2.1A is possible to drive 40 units of toxic gas detector,
or 15 units of flammable, infrared gas detector.
|
||||
|
Working method
|
Fixed type installation, online detection, diffusion type measurement
|
||||
|
Protection level
|
IP65
|
||||
|
Explosion-proof mark
|
ExdⅡCT6, certificate number: CNEx15.1283
|
||||
|
Exterior dimensions
|
233×205×65mm (L×H×W)
|
||||
|
Weight
|
1.0 Kg
|
||||
|
Standard accessories
|
Manual, qualification certificate, warranty card, outer packaging box
|
||||
APPLICATION
All the cases which requires the portable rapid detection of gas concentrations such as petroleum, chemical, pharmaceutical, environmental protection, combustion gas distribution, warehousing, smoke gas analysis, air governance, and so on.
