0.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100

Place of Origin China
Brand Name Zetron
Certification CE
Model Number MIC-100
Minimum Order Quantity 1 piece
Packaging Details paper carton
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Fixed Gas Detector Gas Unit PPM
Alarm Audible+Visual Warranty 12 Months
Weight 1.6(kg) Size 180*140*92mm (L*H*W)
High Light

mic100 oxygen gas detector

,

electrochemistry sensor oxygen gas detector

,

mic100 o2 gas detector

Leave a Message
Product Description

MIC100 Series
Online Toxic and Harmful Gas Detector



OVERVIEW


MIC100 Series gas detector can be used in 24 hours continuous online monitoring of concentrations of single gas in the field. The types for detection are more than 500 types.
Output can be simply integrated into a Distributed Control System (DCS) to provide warnings and enable control of high levels in the working environment.
The strong, durable, and explosion-proof shell and fluorocarbon surface treatment process is suitable for use in a variety of hazardous places and corrosive environments, it is wear-resistant.

0.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 00.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 10.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 20.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 30.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 40.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 50.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 60.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 70.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 80.01% VOL Resolution Oxygen Gas Detector Electrochemistry Sensor MIC100 9



FEATURES



◆ Imported Sensors, Accurate, Fast and Stable
①It can be used in 24 hours continuous online monitoring of gas concentration, and the types for detection are more than 500 types.
②The gas units can be customized: Normally PPM, %Vol, %LEL, other: mg/m3, PPHM, ppb, mg/l.

◆ Diversified Data Communication Methods
① It is possible for real-time monitoring via wired or remote wireless transmission and network transmission.
② Three-wire system 4 ~ 20mA standard signal and standard bus RS485 (mod bus-RTU) simultaneous output.
③ It is possible to select frequency output 200-1000Hz, Hart protocol signal, 1 ~ 5V output, SMS alarm, and wireless transmission.



◆ Infrared Remote Control
Standard configuration includes the infrared remote control, it is possible for one-key operation via an infrared remote control function key, which can achieve the operation without opening the cover in hazardous situations. such as the functions like modification of the alarm point, density calibration, zero-point calibration, noise reduction, restoring the factory setting, and so on.



SPECIFICATION



Gas
Carbon Monoxide
Sensor
Electrochemical
Range
0-500,1000,2000ppm
Can be customized
Resolution
0.1 ppm; Can be customized
Sampling Method
diffusion/pump
Control Method
Controller/Infrared remote control
Allowable error
≤±3% FS; Can be customized
Work Method
24-hour continuously monitoring
Response time
T90≤20 seconds; Can be customized
Recovery time
≤10 seconds; Can be customized
Voltage
≤2.5 W(DC24V)
Power
12~30VDC
Alarm
Audible;Light(option)
Display
LCD/without LCD Display
Cable
PVVP3 * 1.0mm 2
Transmission Distance
≤1000m
Installation
Wall-mounted; Ceiling-mounted;Vertical pipe-mounted; Horizontal pipe-mounted
Size(mm)
180*140*92
Weight(Kg)
1.6
Kit
Manual, qualification certificate, warranty card, outer packaging box

APPLICATION



All the cases require the fixed installation, and online detection of gas concentrations such as petroleum, chemical, pharmaceutical, environmental protection, combustion gas distribution, warehousing, smoke gas analysis, air governance, and so on.
