Adopted advanced microprocessor control technology, long life pulse mode light source, using the characteristics of ozone to UV light absorption, according to Beer-Lambert (Beer-Lambert) law, the People's Republic of China national environmental standards "ambient air ozone determination ultraviolet photometric method", the Ministry of Construction of the People's Republic of China "ozone generator for water treatment It is designed and manufactured with the features of long design life, high data stability, and accuracy, easy to use, maintain and operate, etc. Using UV lamps as the light source system, the lamp life is more than 20,000 hours, stable measurement data, high precision; using an integrated shunt layer light cell structure, with no leakage, high-pressure resistance, resistance to the impact of large flow sampling gas, easy to clean, easy maintenance, simple operation. And the internal configuration of the gas filter ensures that the use of the process, keeps the light cell clean, to avoid dust into the zero point drift and data drift. In the process of use, the equipment automatically has zero calibration, to ensure the accuracy of the concentration and avoid zero drift, standard with 4-20mA signal output.
Test method: UV absorption method, the instrument automatically zero calibration, to avoid zero point drift, and to ensure the accuracy of data.
Product advantages: data refresh every second, real-time sampling online testing.
Light source system: long-life UV light source (253.7nm), the
Working mode: built-in long-life suction air pump to ensure stable sampling
Intelligent compensation: built-in light source automatic compensation function, built-in temperature sensor (compensation), built-in pressure sensor (compensation).
Measuring range: extremely wide testing range 0-1000PPM; (optional 0-100PPM range).
Compact size: 145*70*165mm, lightweight and easy to carry.
Data display LED display with optional backlight for clear reading in the dark.
Output function: standard 4-20mA current signal output or optional RS-485 communication.
It is mainly used for monitoring the ozone concentration of air conditioning inlet and return air outlets, evaluating the ozone oxidation capacity of analyzers, detecting the concentration of ozone sterilization cabinets, detecting the ozone source of medical devices, ozone experiments, research, sewage treatment engineering, and other project applications.
Tag: Ozone gas analyzer,Gas concentration analyzer,Ozone monitor,Ozone concentration detector,Tabletop ozone detector,High-precision ozone gas analyzer, OEM/ODM services.
